Model No. CRT-571
SPECIFICATION
Date 2010/01/10
Ver. 1.0
Card Dispenser
Page
3/10
3. General Specification
·Power Supply:
DC 24V ±5%
·Current Comsumption:
Static Current: 0.1A
Peak Current During Operation: 1.5A
Normal Current Condition: 700mA
·Card Feeding-Out Speed:
> 1Cards/s
·Communication Interface:
RS232C
·Card Dimensions:
Size: 55×86mm
Thickness: 0.36~1.0m
·Weight:
2.0 Kg Approx.
·Dimensions:
Refer to Structure And Dimension Drawings
·Card Stacking Capability:
120pcs in case of 0.76mm standard card
( Available to set to 500pcs max.)
·Card Pre-Empty Detection:
7~50pcs ± 2pcs ( Default setting: 15pcs)
·Enviromental Condition:
Operation: 0~50℃ 0~90% RH ( Without Condensing)
Storage: -10~75℃ 0~90% RH ( Without Condensing)
·Lift Time:
500 thousand times
( In the condition: 20±5%, 35~60%RH, ≥ 1pcs/min)
·Support ISP Download On Line
·Compliant To RoHS
To Next Page
