Model No. CRT-571
SPECIFICATION
Date 2010/01/10
Ver. 1.0
Card Dispenser
Page
4/10
4. CRT-571 Design Specification
4.1 Card Thickness Adjustment
CRT-571 makes it more accurate and convenient to dispense the cards in
different thickness via rotating the turn-knob to different gear position so as
to adjust the gap between the upper and lower transmiting wheels, which
eliminates the inconvenient and inaccurate gap adjustment defects. With
this feature, CRT-571 is quite suitable for the unattended vending devices
to dispense various cards of distinct thickness.
There are several steps to adjust the thickness of cards:
1. Confirm the thickness of cards ( Raised type character are not
involved in)
2. Press the turn-knob and turn around to the graducation pointed by
the red arrow. Seeing pictures below.
3. Make sure the adjustment on the right position by insert cards from
stacker. (Inserting one card from stacker will be smooth and two
cards simultaneously from behind can be impossible)
