6. Multi-Unit Communication Setting
6.1 DIP Setting Of Unit Address
The following table shows the Dip setting of Unit Address.
Multi-switch
4 3 2 1
Corresponding address
ON ON ON ON ‘00’
ON ON ON OFF ‘01’
ON ON OFF ON ‘02’
ON ON OFF OFF ‘03’
ON OFF ON ON ‘04’
ON OFF ON OFF ‘05’
ON OFF OFF ON ‘06’
ON OFF OFF OFF ‘07’
OFF ON ON ON ‘08’
OFF ON ON OFF ‘09’
OFF ON OFF ON ‘10’
OFF ON OFF OFF ‘11’
OFF OFF ON ON ‘12’
OFF OFF ON OFF ‘13’
OFF OFF OFF ON ‘14’
OFF OFF OFF OFF ‘15’
