5. Sensor And Card Stop Position
Sensors and card stop position show as below:
Front side without holding card
Front side holding card IC Contact
Card stacker
IC Card operation position
RF Card operation position
Sensor 6 Position 1
Sensor 6 Position 2
Card collection position
Collection Clips
IC Contact
