Creda CAR 033 - Minimum Mounting Clearance

Fig. 3
Template
Fig. 2Fig. 1
Shelf
119 mm
300 mm
300 mm
150 mm (Min)
150 mm
(Min)
150 mm
(Min)
570 mm
A mm
Minimum mounting clearance
*Plase note correct product orientation.
