INSTALLATION INSTRUCTIONS
Double Pole
Control Switch
Single Oven
in tall
Cabinet
585mm max
575mm if cooker
trim is to
overlap
top edge
of shelf
*excluding pipes
and other
projections
6mm
2
Cable if Hotplate
fitted
Conduit Box
4mm
2
Cable if hob fitted
adjacent to oven
4mm
2
Cable
to Oven
Refer to Electrical Installation
560mm min
574mm max
*550mm
Fig. 4
Fig. 5
