Creda REFLECTION User Manual

32
Ventilation Slot
if cabinet doesn't fit to ceiling
51 x 457mm min area
Ventilation Slot
if cabinet fits
to ceiling
51 x 457mm min
area
50mm
air
gap
50mm
air
gap
Tall Cabinet
As Above
Built
Under
560mm min
574mm max
550mm min
excluding pipes
and other projections
575mm min
580mm max
When fitting a hob above an oven always
use these installation instructions
in conjunction with the hob instructions.
Use 2.5mm
2
High Temp Cable. Refer to
Electrical Installation.
Oven
Fig. 1
Fig. 3
1.5mm
INSTALLATION INSTRUCTIONS
560mm
Viewed down through
cabinet
Fig. 2
Cabinet
Side
Trim
No. 6 x 15mm
(4 Supplied)
Oven Door
