Creda TSRE050 - Technical Details

All Models
Controls
Digitally controlled, Electronic Thermostat accurate to (±0.2oC). Setpoint range (7-26°C)
Timer modes: 7 Day Programmable User Timer, Out All Day, Holiday
Controller UI
•Graphical display with white backlight
•Capacitive buttons with audio feedback
•User replaceable battery (Coin-Type)
Controller Functions
•Open window detection
•Boost Mode and Settings
•Heat Demand % Adjustment
•History/Reporting
•Automatic Charge Control
•Bluetooth for software updates
•Child Lock
Safety Features
Electronic overheat protection. Additional electromechanical overheat protection.
LVD and EMC compliance.
Storage Core High-density bonded magnetite energy cells
Colour/ Finish White (RAL 9016) ‘Trac White’. Grill RAL7035 anodised
Battery Backup 3.3V coin cell battery to backup real time clock. Battery life > 5 years.
Supply (each) 1/N/PE 230-240V / 50Hz (Peak / O Peak) Class II
IP Rating IPX4
Approvals CE & BEAB
Warranty 2 Years
Country of Origin United Kingdom
Technical Details
Models
TSRE050 TSRE070 TSRE100 TSRE125 TSRE150
Input Rating +5% / -10% 1020W 1560W 2220W 2760W 3300W
Nominal Output (kW) 0.50 0.70 1.00 1.25 1.50
Storage Element Rating 230/240V~: 936/1020W 1435/1560W 2042/2220W 2540/2760W 3024/3300W
Rated Charge Period: 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours 7.7 - 7 Hours
kWh: 7.14kWh 10.9kWh 15.5kWh 19.3kWh 23.1kWh
Fan Wattage 11W 11W 11W 11W 11W
UI Wattage 0.5W 0.5W 0.5W 0.5W 0.5W
Sound Level dB 27 29 32 30 31
Energy Cell Packs Required
(047243)
4 6 8 10 12
Installed Weight: 63kg 85kg 107kg 133kg 155kg
Height (mm) 749 749 749 749 749
Width (mm) 581 703 825 947 1069
Depth (mm) 182 182 182 182 182
