Page 12 Crest Audio CPA Series Power Amplifiers
Models CPA400, CPA600, CPA900, CPA1200, CPA1800
Stereo Mode Connections
(5-Way Output Binding Posts)
NOTE: the Binding Post version
of the CPA1800 features two pair
of 5-Way Output Binding Posts.
Parallel Mode Connections
(5-Way Output Binding Posts)
Bridged Mono Mode Connections
(5-Way Output Binding Posts)
