Crestron CEN-GW1 - Make Connections

DIN Rail
To mount the CEN-GW1 to a DIN rail:
1. Hang the mounting bracket on the top of the DIN rail and press the
bottom toward the DIN rail until it snaps into place.
2. Insert the CEN-GW1 into the mounting bracket until it snaps into
place.
3. Secure the CEN-GW1 to the mounting bracket. Insert a6-32x3/8in.
screw into each side of the mounting bracket and tighten using a
Phillips screwdriver.
NOTE: Do not use the included screws to mount the bracket to
the bottom of the CEN-GW1. Doing so will prevent removal of
the CEN-GW1 from the DIN rail.
Make Connections
Make the Power, Ethernet, and Antenna connections.
Turn on power to the CEN-GW1 after all connections have been made.
Use Crestron power supplies for Crestron equipment.
3
CEN-GW1 and CENI-GW1
QuickStart
Universal Wireless Gateway - ER, SG, and infiNETEX® Wireless Networks
