High Powered RF Gateway Crestron CEN-HPRFGW
Acquiring the
Touchpanel
Touchpanels can communicate with a CEN-HPRFGW only if they have
been acquired by that CEN-HPRFGW. The Acquire mode can be
activated from Crestron Toolbox (recommended) or with the ACQUIRE
button on the CEN-HPRFGW.
NOTE: To access this in Toolbox, select Functions | High Power RF
Gateway…. Refer to the Toolbox Help file and search for “High Power
RF Gateway” for more details.
NOTE: The Acquire mode can be activated approximately 15 seconds
after applying power to the CEN-HPRFGW.
NOTE: In an environment with multiple gateways, only one gateway
should be in the Acquire mode at a time.
NOTE: The CEN-HPRFGW must be placed in Acquire mode before a
touchpanel is placed in the Acquire mode.
To acquire a touchpanel via the ACQUIRE button on the
CEN-HPRFGW:
1. Press ACQUIRE on the CEN-HPRFGW to enter the Acquire
mode. The accompanying LED will illuminate, indicating the unit
is ready to link to touchpanels.
NOTE: The Acquire mode will automatically deactivate after one
hour. This default timeout period can be changed from Toolbox.
2. Place the closest touchpanel in the Acquire mode as described in
its manual. The device will be automatically acquired by the
gateway within two minutes after it enters Acquire mode.
3. Repeat step 2 for each touchpanel to be acquired.
4. Press AQCUIRE on the CEN-HPRFGW to exit the Acquire mode.
The LED will turn off.
24 • High Powered Gateway: CEN-HPRFGW Operations & Installation Guide – DOC. 6587B
