Crestron CP3 User Manual

Crestron CP3 & CP3N 3-Series Control Systems
Operations Guide – DOC. 7316C 3-Series Control Systems: CP3 & CP3N • 1
3-Series Control Systems: CP3 &
CP3N
Introduction
The Crestron
®
CP3 and CP3N present a new benchmark in control system
technology. Featuring the Core 3 OS™ control engine, the CP3 and CP3N form the
core of any modern networked home or commercial building, managing and
integrating all the disparate technologies throughout a facility to make life easier,
greener, more productive, and more enjoyable.
The CP3N is an enhanced version of the CP3 featuring a dedicated CONTROL
SUBNET port.
The CP3 and CP3N are generally identical. For simplicity within this guide, the term
“CP3” is used except where noted.
Features and Functions
(Continued on following page)
• Next generation control system
• Core 3 OS - substantially faster and more powerful than other control
systems
• Exclusive modular programming architecture
• Vector floating point coprocessor
• Onboard 512 MB RAM and 4 GB flash memory
• Expandable storage up to 1 TB
• Rear panel memory card slot
• High-speed USB 2.0 host port
• Industry-standard Ethernet and Cresnet
®
wired communications
• Control Subnet provides a dedicated local network for Crestron devices
(CP3N only)
• Onboard e-Control
®
Web server
• Supports Core 3 UI™ XPanel Web-based remote control
• Supports Crestron Mobile
®
control apps for iPhone
®
, iPad
®
, and
Android™
• Supports Fusion RV
®
and SNMP remote management
• One RS-232/422/485 COM port with hardware and software
handshaking
• Two RS-232 COM ports with software handshaking only
• Eight IR/serial, eight relay, and eight Versiport I/O ports

Crestron CP3 Specifications

General

Motherboard chipset	-
Processor frequency	- GHz
Storage media	Flash
Card reader integrated	Yes
Total storage capacity	4 GB
Compatible memory cards	MMC
Internal memory	0.5 GB
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Serial interface type	RS-232/422/485
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	5 - 45 °C
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
