Crestron CP3 & CP3N 3-Series Control Systems
Operations Guide – DOC. 7316C 3-Series Control Systems: CP3 & CP3N • 5
CP3 Specifications (Continued)
SPECIFICATION DETAILS
Memory
SDRAM 512 MB
Internal Flash 4 GB
Memory Card Expandable storage up to 32 GB
(SD™ memory card not included)
External Storage Up to 1 TB using USB mass storage device
(not included)
Communications
Ethernet 10/100 Mbps (10/100/1000 Mbps on CP3N);
auto-switching, auto-negotiating,
auto-discovery, full/half duplex, industry-
standard TCP/IP stack, UDP/IP, CIP, DHCP,
SSL, IEEE 802.1X; SNMP; BACnet/IP
1
;
IPv4 or IPv6, Active Directory authentication,
IIS v.6.0 Web Server, SMTP e-mail client,
installer setup via Crestron Toolbox or
MSIE
2
; supports all e-Control, Core 3 UI
XPanel, Crestron Mobile, Crestron Fusion™
and RoomView
®
applications
Control Subnet (CP3N Only) 10/100/1000 Mbps Ethernet, auto-switching,
auto-negotiating, auto-discovery, full/half
duplex, DHCP server, DNS server, port
forwarding, Isolation mode
Cresnet Cresnet master mode
USB Supports USB HID and USB mass storage
class devices via rear panel USB 2.0 host
port, supports computer console via front
panel, USB 2.0 device port
RS-232/422/485 For 2-way device control and monitoring, all
ports support RS-232 up to 115.2k baud with
software handshaking, one port also
supports hardware handshaking, RS-422,
and RS-485
IR/Serial Supports 1-way device control via infrared
up to 1.2 MHz or serial TTL/RS-232
(0-5 volts) up to 115.2k baud
Power Requirements
Power Pack 2.0 amps @ 24 volts dc,100-240 volts ac,
50/60 Hz power pack, included
Available Cresnet Power 24 watts (1 amp @ 24 volts dc) when using
power pack
Cresnet Power Usage 15 watts (0.625 amp @ 24 volts dc) when
using Cresnet network power
Net ID
3
02
(Continued on following page)

Crestron CP3 Specifications

General

Motherboard chipset	-
Processor frequency	- GHz
Storage media	Flash
Card reader integrated	Yes
Total storage capacity	4 GB
Compatible memory cards	MMC
Internal memory	0.5 GB
Wi-Fi	No
Cabling technology	10/100Base-T(X)
Serial interface type	RS-232/422/485
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
VGA (D-Sub) ports quantity	0
AC input voltage	100-240 V
AC input frequency	50 - 60 Hz
Operating temperature (T-T)	5 - 45 °C
Product color	Black
Rack capacity	1U

Weight and Dimensions

Depth	167 mm
Width	439 mm
Height	44 mm
Weight	1420 g
