Crestron DM NAX X-Series Quick Start Guide

100-240V~
1.2-0.6A
50/60 Hz
(1) IEC 60320 C14 main power inlet;
Mates with removable power cord, included
Ethernet 1 (1)8-wire RJ45 female;
100Base-T/1000Base-TX Ethernet port
Ethernet 2 (1) 8-wire RJ45 female;
100Base-T/1000Base-TX Ethernet port
Controls and Indicators
PWR
(1)LED;
White indicates amplifier is on and ready for
use;
Amber indicates the amplifier is booting;
Red indicates amplifier is in standby
HI-Z
(1) White LED;
Indicates when Hi-Z mode is enabled (70V or
100V)
LAN (1) White LED;
Indicates that the device has a valid IP
address
AoIP (1) White LED;
Indicates an active AoIP stream
FAULT (4) Red LEDs (one per speaker output);
Indicates that the input channel has a fault or
is clipping
SIGNAL (4) White LEDs (one per speaker output);
Indicates an active input signal
LOCKOUT
(1) Red LED;
Indicates that rear panel slide switches are
being overridden by programmatic or web
UIcontrol
Lo-Z MODES
(2) Slide switches, one switch controlling
channels 1 and 2, and one switch controlling
channels 3 and 4;
Selects stereo, summed, or bridged operation:
l
STEREO: The input signal received on
each channel is sent to its respective
output for use in applications where left
and right channel separation is required.
l
SUM: The input signals sent to a channel
pair (1 + 2 or 3 + 4) are summed and sent
to their respective individual outputs.
l
BRIDGE: The input signals sent to a
channel pair (1 + 2 or 3 + 4) are summed
and sent to a bridged output (1 + 2 or 3 +
4) for use in high power applications.
Operations
Mode
(1) Slide switch;
Sets the amplifier for Lo-Z (4or 8 Ω) or Hi-Z
operation (70V or 100V)
Power Mode (1) Slide switch;
Selects Power Saveror Always On operation
SETUP (1) Red LED and push button;
Utilized in some restore procedures
Power
Main Power 1.2-0.6A @ 100-240VAC, 50/60 Hz
Power
Consumption
75 W (All channels driven at 1/8th power, 8
ohms)
Environmental
Temperature 41 to 104°F (5° to 40°C)
Humidity 10% to 90% RH (non-condensing)
Heat
Dissipation
130 BTU/hr
Dimensions
Height 1.74 in. (44 mm)
Width 9.38 in. (238 mm)
Depth 11.03in. (280 mm)
Weight
5.3 lb (2.4 kg )
Compliance
Regulatory Model:M1845006
UL®Listedfor US & Canada, CE, IC, FCC Part 15 Class B
digital device
Model
DM-NAX-AMP-X300
DM NAX™ X-Series Flexible Output Amplifier, 300W
Available Accessories
For a list of available accessories, visit the
DM-NAX-AMP-X300 product page.
Note:
1. 3 channel operation requires two single ended loads and one bridged load.
DM-NAX-AMP-X300
DM NAX™ X-Series Flexible Output Amplifier, 300W
