Subwoofer Output
The HD-XSPA has speaker level and line-level subwoofer outputs. The
speaker level output (SPEAKEROUTPUTS) can be used with a passive
subwoofer while the line-level output (PREAMPOUT SUB) can be used
with an active subwoofer or a separate subwoofer amplifier.
Preamp Out Downmix
The PREAMP OUT DOWNMIX output can be configured to provide an
unbalanced stereo or mono downmix of the selected input signal to feed a
second listening zone or headphone amp through the left and right
preamp outputs.
When configured for stereo operation, the input signal is downmixed to a
stereo signal with left and right channel separation that is available on the
left and right preamp outputs.
When configured for mono operation, the input signal is downmixed to a
mono signal that is available on both the left and right preamp outputs.
Configure
While the HD(I)-XSPA can be used right out of the box, the device can be
further customized with Crestron Toolbox software or the front panel
controls. For details on using Crestron Toolbox software, refer to the
Crestron Toolbox help file. For details on using the front panel controls,
refer to the HD(I)-XSPA Supplemental Guide (Doc. 7448).
