PROCISE™ Surround Sound Processor Crestron PSPHD
PSPHD Specifications (Continued)
SPECIFICATION DETAILS
Audio – Downmix
L/R Output Level
Mono Output Level
Bass Control
Treble Control
-80dB to +20dB, adjustable from 0% to
100%, plus mute
-80dB to +20dB, adjustable from 0% to
100%, plus mute
±12.0 dB per output
±12.0 dB per output
Audio – 3-Channel Input Mixer
Mix Level
Input Compensation
EQ Mode
GEQ Center Frequencies
GEQ Gain
Notch Filter Frequency
Notch Filter Width
Dynamics Processing
Dynamics Pre-Process Level
Gating Level (Threshold)
Gating Depth (Attenuation)
Gating Attack
Gating Decay (Release)
Compression Level
(Threshold)
Compression Ratio
Compression Attack
Compression Release
Compression Curve
Dynamics Post-Process Level
Mixer Input Presets
-80.0 to 0.0 dB per channel (Mix 1-3), per
output (Front L/R, Surround L/R, Back L/R,
Center, Stereo Downmix, Mono Downmix)
±10.0 dB per input
4-band graphic plus 2 notch filters (per input)
160, 500, 1.2k, 3k Hz
±12.0 dB per band
20 to 20,200 Hz per filter
0.020 to 3.500 octaves per filter
Gating and compression (per input)
±12.0 dB
0-100%
0.0 to 80.0 dB
0 to 100 ms
0 to 5000 ms
-80.0 to +20.0 dB
1.0:1 to 10.0:1
0.1 to 300.0 ms
1 to 1000 ms
Hard or soft knee
±12.0 dB
1 thru 30
Audio – Master Mixer
Program Level
Mixer Level
Master Mixer Presets
-80.0 to 0.0 dB plus mute per output group
(Main, Stereo Downmix, Mono Downmix)
-80.0 to 0.0 dB plus mute per channel (Mix
1-3), per output group (Main, Stereo
Downmix, Mono Downmix)
1 thru 10
(Continued on following page)
