TSW-750 7” Touch Screen
crestron.com
|
800.237.2041
TableTop Option
Using the optional TableTop Kit (TSW-750-TTK
[2]
), the TSW-750 becomes
a stylish, freestanding touch screen that fits perfectly on a table, desk, or
countertop. It can even be permanently attached to the surface using the
optional Swivel Mount Kit (TSW-550/750/1050-SMK
[2]
).
SPECIFICATIONS
Touch Screen Display
Display Type: TFT Active matrix color LCD
Size: 7 inch (178 mm) diagonal
Aspect Ratio: 15:9 WVGA
Resolution: 800 x 480 pixels
Brightness: 300 nits (cd/m²)
Contrast: 350:1
Color Depth: 18-bit, 262k colors
Illumination: Edgelit LED
Viewing Angle: ±70° horizontal, ±65° vertical
Touch Screen: Projected Capacitive
Buttons
Hard Keys: (5) Projected capacitive pushbuttons, programmable,
pre-labeled with icons for “Power”, “Home”, “Lights”, “Up”, and “Down”
Reset: (1) Miniature pushbutton on rear panel for hardware reset
Memory
LPDDR2 RAM: 1 GB
Flash: 4 GB
Maximum Project Size: 512 MB
Graphics Engine
Supports Smart Graphics
™
[1]
Communications
Ethernet: 10/100 Mbps, auto-switching, auto-negotiating, auto-discovery,
full/half duplex, DHCP, IEEE 802.3af and 802.3at Type 1 compliant
Video
Streaming Formats: H.264 (MPEG-4 part 10 AVC), MJPEG
Audio
Features: Built-in microphone and speakers, Rava
™
SIP Intercom
Audio Feedback Formats: MP3
Connectors
LAN PoE: (1) 8-wire RJ45 with 2 LED indicators;
10Base-T/100Base-TX Ethernet port, Power over Ethernet compliant;
Green and yellow LEDs indicate Ethernet port status
Power Requirements
Power over Ethernet: IEEE 802.3af (802.3at Type 1) Class 3 PoE Powered
Device
Environmental
Temperature: 32° to 112°F (0° to 45°C)
Humidity: 10% to 90% RH (non-condensing)
Heat Dissipation: 44 BTU/hr
Enclosure
Construction: Plastic, smooth black or white finish
Mounting: Surface mount over a 2 or 3-gang electrical box, 2-Gang
European (DIN 49073) electrical box, or 2-3/8” H x 3-3/8” W (60mm H x
86mm W) cutout
[4]
; additional wall mount and tabletop options available
separately
Dimensions
Height: 4.74 in (121 mm)
Width: 7.59 in (193 mm)
Depth: 2.03 in (52 mm)
Weight
14.1 oz (400 g)
MODELS & ACCESSORIES
Available Models
TSW-750-B-S: 7” Touch Screen, Black Smooth
TSW-750-W-S: 7” Touch Screen, White Smooth
Available Accessories
TSW-750-TTK: TableTop Kit for TSW-750 [specify color]
TSW-550/750/1050-SMK: Swivel Mount Kit for TSW-750-TTK
TSW-UMB: Universal Mounting Bracket
TSW-UMB-PMK: Pre-Construction Mounting Kit for TSW-UMB
TSW-550-BBI: Wall Mount Back Box for TSW-UMB – International Version
TSW-RMB: Retrofit Mounting Brackets
PWE-4803RU: PoE Injector
CEN-SW-POE-5: 5-Port PoE Switch
CEN-SWPOE-16: 16-Port Managed PoE Switch
CEN-NVS200: Network Video Streamer
SW-VMK-WIN: TouchPoint
®
Virtual Mouse & Keyboard Software for
Windows
®
Notes:
1. Supports Smart Graphics only. Not compatible with “traditional” UI projects.
2. Item(s) sold separately.
3. H.264 compatible IP camera required.
4. For proper positioning of the touch screen unit, the electrical box or cut-out must be positioned
approximately 1/4” to the right of center, and 1/10” above center.
