CREVIS GT-5 Series User Manual

10 FnIO G-Series
Copyright(C)CREVIS Co.,Ltd Support +82-31-899-4599 URL: www.crevis.co.kr
2.1.4. Specification
Items
Specification
Input Specification
Number of Channel
2 Channel
- Encoder, High Speed Counter, Frequency measurement
Pulse width & Period measurement
Indicators
4 Green Terminal Input LEDs
Input Voltage
5Vdc(Max)
Input Current
13mA@5.2Vdc
Min On-State Volt
≥2.1Vdc
Max Off-State Volt
≤2.0Vdc
Input Frequency
0~600KHz Encoder Mode
0~1MHz Counting Mode
Counting Mode
1-Input Mode : Up,Down
2-Input Mode : Encoder 4x, Up/Inhibit, Up/Reset, Down/Inhibit
down/Reset, UP/Down, Clock/Direction,
Frequency Measurement,
Pulse Width & Period measurement
Counter Size
32bit-wide/Channel
General specification
Power Dissipation
70mA maximum @ 5.0Vdc
Isolation
I/O to Logic : Photocoupler isolation
I/O to Field Power : Non-Isolation
Field Power (Bypass)
Supply voltage : 24Vdc nominal
Voltage range : 18~32Vdc
Wiring
I/O Cable Max. 2.0mm
2
(AWG 14)
Weight
60g
Module Size
12mm x 90.5mm x 65mm
Environment Condition
Refer to ‘1. Environment Specification'

CREVIS GT-5 Series Specifications

General

Brand	CREVIS
Model	GT-5 Series
Category	Control Unit
Language	English
