15 FnIO G-Series
Copyright(C)CREVIS Co.,Ltd Support +82-31-899-4599 URL: www.crevis.co.kr
2.2.1.2. LED Indicator
2.2.1.3. Channel Status LED
LED No.
LED Function / Description
LED Color
RxD
Received Data
Green
TxD
Transmit Data
Green
RTS
Request-to-send
Green
CTS
Clear-to-send
Green
LED
Color
Status
RxD
GREEN
Received Data
TxD
GREEN
Transmit Data
RTS
GREEN
Request-to-send
CTS
GREEN
Clear-to-send
