CREVIS GT-5 Series User Manual

29 FnIO G-Series
Copyright(C)CREVIS Co.,Ltd Support +82-31-899-4599 URL: www.crevis.co.kr
GT-5212,5232_image data (Input, Output Data Size : Default, 16Byte)
IO Input
IO Output
Byte#0
Ch#0 Status
Byte#0
Ch#0 Control
Byte#1
Ch#0 RxLength
Byte#1
Ch#0 TxLength
Byte#2
Ch#0 RxData#0
Byte#2
Ch#0 TxData#0
Byte#3
Ch#0 RxData#1
Byte#3
Ch#0 TxData#1
Byte#4
Ch#0 RxData#2
Byte#4
Ch#0 TxData#2
Byte#5
Ch#0 RxData#3
Byte#5
Ch#0 TxData#3
Byte#6
Ch#0 RxData#4
Byte#6
Ch#0 TxData#4
Byte#7
Ch#0 RxData#5
Byte#7
Ch#0 TxData#5
Byte#8
Ch#1 Status
Byte#8
Ch#1 Control
Byte#9
Ch#1 RxLength
Byte#9
Ch#1 TxLength
Byte#10
Ch#1 RxData#0
Byte#10
Ch#1 TxData#0
Byte#11
Ch#1 RxData#1
Byte#11
Ch#1 TxData#1
Byte#12
Ch#1 RxData#2
Byte#12
Ch#1 TxData#2
Byte#13
Ch#1 RxData#3
Byte#13
Ch#1 TxData#3
Byte#14
Ch#1 RxData#4
Byte#14
Ch#1 TxData#4
Byte#15
Ch#1 RxData#5
Byte#15
Ch#1TxData#5
- 1channel Input, output data size : 8Byte
- Default Input, output data All size : 16Byte
- Can be set IO data size Even number
(If set to an odd number IO data size, Automatically changes to an even number)
