- Step#2
RA inverting (RA=RR)
Input Length = 14byte
Input Data = “Company:CREVIS”
bit#7
bit#6
bit#5
bit#4
bit#3
bit#2
bit#1
bit#0
Status Byte #0
TRA
FTA
FRA
RE
RBO
RR
TA
IA
0
0
0
0
0
1
0
0
RX Length #1
‘ 0E'(14byte)
Output Byte #2
‘C' (0x43:ASCII code)
Output Byte #3
‘o' (0x6F)
Output Byte #4
‘m' (0x6D)
Output Byte #5
‘p' (0x70)
Output Byte #6
‘a' (0x61)
Output Byte #7
‘n' (0x6E)
Output Byte #8
‘y' (0x79)
Output Byte #9
‘:’ (0x3A)
Output Byte #10
‘C’ (0x43)
Output Byte #11
‘R’ (0x52)
Output Byte #12
‘E’ (0x45)
Output Byte #13
‘V’ (0x56)
Output Byte #14
‘I’ (0x49)
Output Byte #15
‘S’ (0x53)
- Step#3
RA inverting (RA≠RR)
bit#7
bit#6
bit#5
bit#4
bit#3
bit#2
bit#1
bit#0
Control Byte #0
TPR
FT
FR
----
----
RA
TR
IR
0
0
0
0
0
0
0
0
