7
Needle Replacement
Removing Needle
1. Gently pull down the front edge of the needle.
2. Pull needle forward.
3. Pull out and remove.
Installing Needle
1. Position the needle with its tip facing down.
2. Line up the back of the needle with the cartridge.
3. Insert the needle with its front end at a downward angle and gently lift the
front of the needle upward until it snaps into place.
Radio Operation
1. Rotate the Function Knob to FM or AM position.
2. Rotate the Tuning Knob for desired radio station.
Note:
• The unit is equipped with a FM wire antenna. To FM improve reception, move the
wire around until the reception is clear without interferences. Do not connect the wire
to any additional antenna.
• The AM antenna is built inside the unit. If AM reception is poor, try to rotate the unit
for better reception.
