How to Mount the Battery Powered Alarm
Drywall
Plastic Anchors
Mounting Bracket
1” Screws
Situation B: No Wood
If no wood is present, use a Phillips
screwdriver to screw the two plastic
wall anchors into the pre-drilled holes
until fully seated. Then secure the
mounting bracket to the wall anchors
using the two 1” screws.
Situation C: Combination
Where there is no wood present, first
screw the plastic wall anchor into
the pre-drilled hole using a Phillips
screwdriver.
Then secure the mounting bracket in
place using the two 1” screws.
Drywall
Plastic Anchors
Mounting Bracket
1” Screws
Wood
4 Lock Into Place
With the alarm activated and the alarms
fully networked together, position the
smoke alarm onto the center of the
bracket and turn clockwise. The alarm
will lock into place.
Note: Smoke alarms are not to be
used with detector guards unless the
combination has been evaluated and
found suitable for that purpose.
