9
Alarm Features and Functions
Power Indicator Light (Green)
On the CFS10 (battery-only powered), the POWER
icon will briefly flash every 30 seconds when the
alarm has been activated.
WIRELESS will flash once per second to indicate the
wireless network is open to accept additional alarms
into the network.
Wireless Networking Light (Blue)
Warning Light (Yellow)
WARNING will flash yellow every 30 seconds,
accompanied by the horn chip to indicate the smoke
chamber needs to be removed and cleaned.
FIRE will flash when the alarm detects sufficient
quantities of smoke or heat. This is accompanied by the
sounding of the horn.
FIRE will stay on continuously if the alarm was triggered
remotely by another alarm on your wireless network.
Fire Warning Light (Red)
WIRELESS will cease to flash one minute after the last
alarm has been added to the network or immediately
after the button has been pressed.
On the CFS10-AC (AC with battery backup), the
POWER icon will run continuously while AC powered.
WARNING can also be activated by a remote signal
from a CO Alarm. In this case, WARNING will be
solid red accompanied by 4 beeps of the horn.
Warning Light (Red)
WARNING will flash red every 30 seconds
accompanied by the horn chirp, for a minimum of 7
days, to indicate Low Battery. Replace the alarm.
FIRE will continue to flash twice per minute (without the
horn) for three days after exiting an alarm condition, or
until the front button has been pressed and released.
WARNING will double flash red every 30 seconds
accompanied by the horn chirp, to indicate that the
alarm’s smoke sensor has reached its End-of-Life.
Replace the alarm.
(RED)
(YELLOW)
