23
(3) PARKING BRAKE LEVER
1
2
The parking brake has two positions. In position (1) the brake is not active,
after shifting to position (2) while stepping down on brake pedal the parking
brake is activated (will brake).
Stepping on the brake pedal will deactivate the parking brake and the lever will
automatically be released and shift to position (1).
(4) TRAVEL DIRECTION LEVER
It controls the power supplied to the rear wheels and regulates the speed of the machine in both
directions. In the basic setting it is equipped with a mechanical cruise control function, which is
automatically deactivated by pressing the brake pedal.
F
Forward
travel
Moving the lever closer to the letter F corresponds to a
higher speed and vice versa
N Neutral The machine is still
R
Reverse
travel
Moving the lever closer to the letter R corresponds to a
higher speed and vice versa
Changing the travel direction from forward to reverse or from reverse to forward
is only possible after stopping the machine. When the brake pedal is stepped on
the gear stick automatically shifts to position „N“.
(5) THROTTLE LEVER
Serves to regulate the engine speed. It has the following three positions:
MAX Maximum engine speed
MIN Minimum engine speed (idle)
(6) CHOKE
For starting a cold engine:
CHOKE Starting a cold engine
