9
Clip SGD
Thetablebelowshowsthe‘alarms’and‘alerts’thatmaybeshownonthedisplayduring
operation.

Alarm AlarmStandard ShownonLCD
Display
AlarmandVibrationDisplay
LowAlarm Exceeds1st
Alarmsetpoint
1
icon&
concentration
Buzzer,LED
Vibration
HighAlarm Exceeds2nd
Alarmsetpoint
2
icon&
concentration
Buzzer,LED
Vibration
Remaininglife Below30days
icon
Lifetime
expiration
Past24months
Servicelifeisover
(ReplacewithanewClipSGD)
Testfailure Failureof
sensortest/
calibration
Display

X

iconwith
beeping
Batterytest Lowpower
Bumptest Bumptest
period
VX
Pressthepushbuttontoturnoff
thealarm
Calibration Calibration
period
Pressthepushbuttontoturnoff
thealarm
⚠ CAUTION
Defaultalarmsetpointsarebasedoncommoninternationalstandards.Itisuser
responsibilitytoensuretheconguredalarmsetpointsareinaccordancewithlocal
regulationsandsiteprocedures.
