8
Setting Up Triple Plus+ and Triple Plus+ IR
III. Setting Up
The Triple Plus+/Plus+ IR has been designed to display as much or as little infor-
mation to the user as is required by the controller of the equipment. On the one
hand it is a four channel measuring instrument with continuous readout, on the
other, a basic alarm only detector with status display and no way of switching it
off. This section describes how to tailor the instrument to the application via the
front panel buttons. The section on Configuring the instrument with Portables
PC software details other adjustments that may be made to the instrument.
3.1 Using the Menu system
To access the SETUP menu press ‘CAL’ button. The screen will display the
following:
MENU EVENT LOG
<< >> QUIT LOG
The four buttons have above them a symbol or word: these are the ‘soft key’
functions currently assigned to that particular key. Use the ON and BACKLIGHT
buttons to scroll left and right, the CAL button to quit the menu system and
the UNMARKED button to select a menu option. View the road map on page
31 for details of Triple Plus+ configuration menu system.
The options available are:
MENU This selects the configuration menu. It is password protected, and
described below
EVENT This marks an event in the data log. There is no menu beneath this
option.
LOG This selects the log menu, described below.
How to enter the configuration Menu
Use the scroll buttons to select the MENU item and press the UNMARKED
button. The screen will display 'Password?' Press the buttons in the following
sequence within 5 seconds to enter the default password: ON, BACKLIGHT,
CAL and UNMARKED. This password can be changed via a PC using Portables
PC software.
