Appendix “B”
PRESSURE DROP TABLE (See INDEX: “Gas Connections” for further details).
The BTU’s for each appliance are listed in the
tables below for reference. Find the maximum
BTU requirements for the appliance(s) purchased
adding the combined BTU’s together. Cross
reference the total BTU’s against “Table 3” to
determine the maximum allowable supply line
length for the BTU’s required. If the supply line
length available does not support the BTU
requirements, the pipe size will need to be
changed accordingly. Please contact a certified
gas technician for additional size options.
BTU Grills: Table 1
BTU’s
LP Pilot
Orifice - 70
BTU’s
LP Burner
Orifice - 56
BTU’s
NG Pilot
Orifice - 57
BTU’s
NG Burner
Orifice - 49
Total BTU’s
NG/LP
MCB30 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
65,000 (60,800)
MCB36 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
80,000 (74,800)
MCB42 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
95,000 (88,800)
MCB48 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
110,000 (102,800)
MCB60 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
130,000 (121,600)
MCB72 (R)
5,000 (4,800)
15,000 (14,000)
5,000 (4,800)
15,000 (14,000)
160,000 (149,600)
(R) Values in parenthesis () are for Residential Grills only.
BTU Side Burners: Table 2
BTU’s
LP Burner
Orifice - 57
BTU’s
NG Burner
Orifice - 49
Total BTU’s
NG/LP
SB-MCB
15,000
15,000
15,000
Maximum Runs for All Appliances
on a supply Line: Table 3
Run Length
3/4 Pipe (in feet)
Max BTU for All
Appliances on Line
10
360,000
20
245,000
30
198,000
40
169,000
50
150,000
60
135,000
70
123,000
80
115,000
