Crown 800CSL - Main Chassis Assembly Parts

Power Base-2 & 800CSL Amplifier Service Manual
19
Mechanical (Non-Module) Parts
MAIN CHASSIS ASSEMBLY
CPN ITEM QTY
A10086-70806 Screw, 8-32-.37 Mach Rd Ph 2
A10094-3 Washer, #6 Black Star 3
A10094-6 Washer, #8 Black Star 4
A10094-8 Washer, #10 Tooth Lock 10
A10099-5 Washer, #8 Nylon Shoulder 4
A10109-10822 Screw, 8-18-1.375 Pan Ph 2
A10110-70812 Screw, 8-32-.75 Taptite Pan Ph 2
A10192-1 Snap Bushing .5 4
C 1811-6 Tie Wrap 4
C 3163-0 Solder Lug #6 505 1
C 6487-0 Power Switch 22A Rocker 2 Pole 1
C 6912-7 Tension Retainer Board Support 2
C 6913-5 Spacer Nut, 1 inch 2
C 6914-3 Spacer Nut, .75 inch 2
C 8341-7 Ferrite Bead 2
C 9491-9 Screw, 6-32-.312 Taptite Pan 4
C 9953-8 Screw, 6-20-.312 Taptite Pan Black 6
D 7600-6 Ground Strap (DBP to Chassis) 1
D 7784-8 Label, Sensitivity Switch 1
D 8002-4 Label, F2 Fuse Replacement 1
D 8067-7 Label, F1 Fuse Replacement 1
F10787J3 Back Panel Plate 1
M21082J8 Chassis 1
Main Module (See Module List) 1
