Crown FM30 - Initial Power-up Procedures

3–2
FM30/100/250 User's Manual
OFF
SCA IN
COMPOSITE IN
MONITOR
R
L
23
REMOTE I/O
RIGHT
LEFT/MONO
B
A
T
T
E
R
Y
36 VDC
+
–
CIRCUIT
BREAKER
1
Possible equipment damage!
Before operating the transmitter for
the first time, check for the proper AC
line voltage setting and frequency
selection as described in sections 2.2
and 2.3.
CAUTION
Illustration 3–1 DC Breaker
1. Turn on the DC breaker.
Illustration 3–2 Front Panel Power Switches
3.1 Initial Power-up Procedures
These steps summarize the operating procedures you should use for the initial
operation of the transmitter. More detailed information follows.
DC Breaker
Main Power
Switch
Carrier
Switch
2. Turn on the main power switch.
