LCD display
FM/AM Mode
Func
M1-M4:
Storage location
Scan
ASQ, SQ,VOL level
RX signal strength,
PWR: TX signal strength.
Current Voltage
Working norm
Current channel
1W/4W: Power level
CH9/19
Dual watch
ASQ
AM/FM mode
1. Short press key to switch between AM/FM
mode.
2. Corresponding mode will displayed in the LCD.
Keypad lock icon
Dot matrix LCD display for channel number, frequency and operations.
2 Digits for display of channel number and Norms
5 Digits for display of frequency and Norms
Transmitting
1. Hold [PTT] key, TX LED indicator light on.
2. Hold the microphone about 2cm away from
your mouth and speaker in a normal tone.
edom XR ot nrut oidar eht ]TTP[ esaeleR .3
TX LED indicator light off.
Receiving
The radio will keep in TX mode when it is not
transmitting, the RX LED indicator will light
on.
