Sampling Pipes
Connect the appropriate sampling pipe to the sampling head.
Sampling pipe DX210-4A
The sampling pipe DX210-4A can be used for all vehicles, but for convenience of
use alternative pipes are available.
DX210-4A
Sampling pipe DX210-6
Sampling pipe DX210-6 is used for vertical exhausts. Hang the sampling pipe and the
sampling head as shown in the illustration. For very high exhausts, an extension pole 1.5 m or
2 m length may be fitted to the sampling head using an extension kit DX260-160L (1.5m) or
DX260-160H (2.0m) as illustrated.
