UM-CV-751-RP-F17-Q113V1 www.rackmountsales.com
RMP-161-F17
USB Touchscreen
Power VGADVI-D HDMI
Model TRB e-Resistive
Technology
5-Wire Resistive
Touch Point
Single
Method
Stylus or Finger
Activation Force
≤ 50g / Stylus=R0.8
Durability
10 million touches
Response Time
15 ms
Optical Transmittance
80% ± 3%
Surface Hardness
3H
Haze
8% ± 3%
Glass
2.2 ±0.2 mm
Connector
USB Type A
Compatibility
Windows 7 / XP / Vista, Linux
< 3.4 > Options : Touchscreen & driver
P.13
F17" USB Touchscreen Specifi cation
Step 1. Run the bundled CD disc from the disc :
Step 2. Double click the Setup.exe
Step 3. Follow the installation instruction to fi nish the setup
Step 4. After installation, run the TouchKit program & the “4 point calibration”
Please follow the below steps to setup the touch screen:-
Please do the initial calibration
after the fi rst setup
■ USB touchscreen package includes 1 x 6ft USB cable, quick reference guideline and CD disc
■ For detailed information, please refer to the attached CD disc
■ As the touchscreen unit is not made of toughened glass, please handle it carefully
