CS Instruments LD 500 Short User Guide

LD 500_SHORT BAL_V2.03 EN Page 3 of 20
2. Intended use
The LD 500 is a leak detector for quick and reliable leak detection in/on compressed air systems.
The LD500 leak detector evaluates the ultrasonic waves generated by the leakage based on distance
and pressure.
It is solely designed and constructed for the intended use described here and may only be used for this
purpose.
The user must verify that the device is suitable for the intended use. The technical data listed in this
datasheet are binding.
Improper handling or operation outside the technical specifications is not permitted. Claims of any
kind for damages arising from improper use are excluded.
3. Technical data LD500
Dimensions hand-held
housing
263 x 96 x 280 mm (with preamp module and acoustic trum-
pet)
Weight
0.55 kg with preamp module and acoustic trumpet,
complete set in case approx. 3.0 kg
Operating frequency
40 kHz (+/-2 kHz)
Power supply
Internal 7.4 V lithium-ion battery
Operating time
> 9 h (continuous operation)
Operating temperature
-5 °C to +40 °C
Charging
ext. battery charger (included in scope of delivery)
Charging time
max.4 h
Storage temperature
-20 °C to +50 °C
Laser
Wavelength 645 – 660 nm, output power < 1 mW
(laser class 2)
Connections
3.5 mm stereo jack for headset,
Power supply socket for connecting an external charger
USB connection
Colour screen
3.5" touch panel TFT transmissive
Interface
USB for data export/import, SW update, etc.
Data logger
4 GB memory card storage (micro SD class 4)
