LD 500_SHORT BAL_V2.03 EN Page 4 of 20
4. The LD 500
5. Preparing the device
The device must be configured before starting the leakage scan. The user can access the menu by
clicking the "Home" button.
Setting the language
Home → Settings → Device Settings → Set Language →
English
USB connection
Plug-in connection for
power supply (battery
charger socket)
Save button
Volume (+/-)
On/Off button
Foil keypad (4 buttons)
Unlock button for preamp
module
3.5" TFT colour display
with touch panel
