Emizon TCD
Technical Specifications
TO TAKE A GPRS SIGNAL STRENGTH - TAP LEFT HAND BUTTON ONCE
TO SEND A TEST SIGNAL - PRESS RIGHT HAND BUTTON FOR 5 SECONDS
TO APPLY A FIRMWARE UPDATE - PRESS BOTH BUTTONS FOR 10 SECONDS
Dimensions 123 mm (h), 180 mm (w), 29 mm (d)
Weight 250 grams
Pins 16 Pin alarm inputs
Power Supply Requirements
11.25v DC to 14v DC
Logic low -0.5V to +0.8V Logic high 3.6V to +30V
Note -The EN54 version of TCD will accept 24V. Please
check
the TCD
Relays
3 Relays Non-Latching - Contact rating is: 1A@30V DC
resistive
10 °C to +50 °C
Lower Battery Threshold Low battery threshold 10.8V +/- 0.2v DC
WARRANTY
CSL will refurbish or replace, at our discretion, any Stand-Alone TCD developing a
fault within 5 Years. All returns must be accompanied with a CSL Returns Number,
this can be obtained by calling the CSL Technical Support as detailed in the
procedure below.
OPEN SOURCE LICENSING
