TP-48 User Manual
29
Chapter 4 Interface
4.1 USB Interface
1.USB (Type A)
PIN
SIGNAL NAME
1
VBUS
2
D-
3
D+
4
GND
2.USB (Type B)
PIN
SIGNAL NAME
1
VBUS
2
D-
3
D+
4
GND
