8 • EN
ERROR LAMP
If the error lamp is lit, check the following:
1. Is the chargers positive lead connected
to the battery’s positive pole?
2. Is the charger connected to a 12V
LiFePO
4
battery?
3. Has charging been interrupted in
STEP 1 or 4?
Restart the charger by pressing the RESET-
button. If charging is still being interrupted, the
battery...
STEP 1: ...can not accept charge.
...may be too large for the charger to
wake up. Press RESET-button up to
5 times.
...a paralell load may be connected to
the battery. Disconnect the battery and
try again.
STEP 4: ...can not keep charge and may need
to be replaced.
POWER LAMP
If the power lamp is lit with a:
1. STEADY LIGHT
The mains cable is connected to the wall
socket.
2. FLASHING LIGHT:
The charger has entered the energy save
mode. This happens if the charger isn´t con-
nected to the battery within 2 minutes or the
battery on board UVP (under voltage protec-
tion) is activated.
READY TO USE
The table shows the estimated time for an empty
battery to reach 90% state of charge (SOC).
Please note that charging times are
longer in low ambient temperatures.
BATTERY SIZE (AH) TIME TO 90% CHARGED
8Ah 2h
20Ah 5h
60Ah 15h
