EN • 13
EN
LITHIUM*
READY TO USE
The table shows the estimated time for empty battery to 80%
charge.
BATTERY CAPACITY
(Ah)
TIME TO 80%
CHARGED
5Ah 2h
10Ah 4h
15Ah 6h
20Ah 7h
25Ah 9h
POWER LAMP
If the power lamp is lit with a:
TIME TO GO
AGM RECONDNORMAL
MODE
CAREGOTRY
HOURS124>8
1. STEADY LIGHT
The mains cable is connected to the wall socket.
2. FLASHING LIGHT
The charger has entered the energy save mode.
This happens if the charger can’t detect a battery
in 2 minutes.
ERROR LAMP
If the error lamp is lit, check the following:
TIME TO GO
AGM RECONDNORMAL
MODE
CAREGOTRY
HOURS124>8
1. Polarity error: Is the charger’s posi-
tive lead connected to the positive
charging point? Is the charger’s
negative lead connected to the
negative charging point?
2. Is the charger connected to a 12V
battery?
3. Has charging been interrupted in
CHECK or CARE?
Restart the charger by pressing the MODE-
button. If charging is still being interrupted, the
battery...
CHECK: ...can not accept charge or paralell
loads may be connected to the battery. Remove
the paralell loads and restart the charging by
pressing the MODE-button.
...restart the charger maximum 3 times. If the
charger doesn´t continue to Bulk after that, the
battery may need to be replaced.
CARE: ...can not keep charge and may need
to be replaced.
*) 12V lithium batteries (LiFePO
4
, Li-Fe, Li-iron, LFP)
