CTEK MULTI XS 3600 Troubleshooting Guide

Trouble Shooting Guide 11
voltage.
Test: Disconnect the battery and try charging again.
Explanation 2: The battery cannot retain the charger given.
Test: The battery needs replacing.
• The error LED is lit
Explanation 1: Reverse polarity.
Test: Make sure that the + cable/clamp is connected to the + terminal and the
– cable/clamp is connected to the – terminal.
Explanation 2: The clamps are short circuited.
Explanation 3: Loads are connected to the battery which requires more power
than the charger can provide.
Test: Turn off or disconnect the loads when charging.

CTEK MULTI XS 3600 Specifications

General

Output	3.6A max
Charging Current	3.6A
Dimensions	165 x 61 x 38 mm
Weight	0.6kg
Output Voltage	14.4V / 14.7V
Battery Capacity	1.2 - 80Ah
Input Voltage	220-240VAC, 50-60Hz
