CTEK MULTI XS 3600 Troubleshooting Guide

Trouble Shooting Guide 13
Explanation 5: The charge cycle is interrupted in step 2.
Test: Test to restart the charge cycle with the mode button, if it still fails in step
2 the battery is can’t be charged and needs to be replaced.
Explanation 6: The charge cycle is interrupted in step 5.
Explanation 6.1: Large loads are connected to the battery and drain the
voltage.
Test: Disconnect the loads and try charging again.
Explanation 6.2: The battery cannot retain the charge provided.
• Temperature LED is lit
Explanation: This led is turned on automatically when the temp sensor is
connected.
• Temperature LED is not lit
Explanation: The temperature sensor is disconnected or has been damaged.
The charger will assume room temperature and charge without temperature
compensation.
• Temperature LED is flashing
Explanation: The temperature is above + 65 °C. The current is reduced until
the temperature has dropped below + 65 °C. The charger reverts to normal
charging current when the temperature drops below + 65 °C.

CTEK MULTI XS 3600 Specifications

General

Output	3.6A max
Charging Current	3.6A
Dimensions	165 x 61 x 38 mm
Weight	0.6kg
Output Voltage	14.4V / 14.7V
Battery Capacity	1.2 - 80Ah
Input Voltage	220-240VAC, 50-60Hz
