CTEK MULTI XS 3600 Troubleshooting Guide

Trouble Shooting Guide 5
• The charger goes into Standby mode after the power is cut and the charging
does not start again
Explanation: The charger will turn into Standby if the voltage in the battery is
below 6V when the power is back on.
Test: Start the charging again by pressing on the mode button.
• The error LED is lit
Explanation: Reverse polarity.
Test: Make sure that the + cable/clamp is connected to the + terminal and the
– cable/clamp is connected to the – terminal.

CTEK MULTI XS 3600 Specifications

General

Output	3.6A max
Charging Current	3.6A
Dimensions	165 x 61 x 38 mm
Weight	0.6kg
Output Voltage	14.4V / 14.7V
Battery Capacity	1.2 - 80Ah
Input Voltage	220-240VAC, 50-60Hz
