GB • 5
SPECIFICATION
MULTI XS 25000
XS 25000
MULTI XT 14000
XT 14000
Voltage AC 170–260VAC, 50–60Hz.
Charging voltage 14.4V 28.8V
Charging current 25A max. 14A max.
Current, mains 2.9A rms (at full charging current)
Back Current Drain* <2Ah per month
Current ripple**
<4%
Ambient temperature -20°C to +50°C Output power is automatically reduced at higher temperatures.
Cooling Fan
Charger type Eight-step, fully automatic
Battery types All types of 12V lead-acid batteries
(WET, MF, AGM and GEL).
All types of 24V lead-acid batteries
(WET, MF, AGM and GEL).
Battery capacity 50–500Ah 28–300Ah, up to 500Ah maintenance
Protection class IP44 (Outdoor use)***
Weight 1.9kg
*) Back current drain is the current that the charger drains from the battery if the AC cord is disconnected.
**) The quality of the charging voltage and charging current are very important. High current ripple heats the battery and ages
the positive electrode. High voltage ripple can damage other equipment connected to batteries. The battery chargers from CTEK
produces very high quality voltage and current with low ripple.
***) IP44 cannot be guaranteed if the charger is not positioned horizontally with the long side or top side turned up.
MAINTENANCE
The charger is maintenance-free. The charger must not be opened; doing so will invalidate the warranty. If the power cable is
damaged it must be replaced by CTEK or its authorized representative. The charger casing can be cleaned using a damp cloth and
mild cleaning agent. Remove the plug from the power socket before cleaning.
LIMITED WARRANTY
CTEK SWEDEN AB, Rostugnsv. 3, SE-776 70 VIKMANSHYTTAN, SWEDEN issues this limited warranty to the original purchaser
of this product. This limited warranty is not transferable. CTEK SWEDEN AB warrants this unit for two years from the date of
purchase against defect workmanship or material. It is the obligation of the purchaser to forward the unit together with proof of pur-
chase to the manufacturer or its representative with transportation cost prepaid. This warranty is void if the unit is abused, handled
carelessly or repaired by anyone other than CTEK SWEDEN AB or its authorized representative. CTEK SWEDEN AB makes no
warranty other than this limited warranty and expressly excludes any implied warranty including any warranty for consequential
damages. This is the only expressed limited warranty and CTEK SWEDEN AB neither assumes nor authorizes anyone to assume
or make any other obligation towards the product other than this limited warranty.
DECLARATION OF CONFORMITY
CTEK SWEDEN AB hereby declares under sole responsibility that the MULTI XS 25000, XS 25000, MULTI XT 14000 and
XT 14000 battery chargers, to which this declaration relates, conforms with the following standards: EN60335-1, EN60335-2-29
following the provisions of directive 73/23/EEC amended by 93/68/EEC and EN61000-3-3, EN61000-3-2, EN55014-1, EN55014-2,
55011 following the provisions of directive 89/336/EEC amended by 92/31/EEC and 93/68/EEC.
Vikmanshyttan Sweden, 01-01-2006
Börje Maleus, Managing Director, CTEK SWEDEN AB
CTEK SWEDEN AB
Rostugnsvägen 3
SE-776 70 VIKMANSHYTTAN
www.ctek.com
