Be careful when carry the batteries as they are heavy.
DO NOT connect the Positive (+) to the Negative (-) battery terminal by any
conductive metals.
Battery Removal：
1.Disconnect two battery plugs (Q) (See Fig. 23).
2.Unfasten velcro strap that hold batteries in place (See Fig. 24).
3.Remove two batteries (S)
(See Fig. 25).
13
Figure 23
Figure 23
Figure 24
Figure 24
Figure 25
Figure 25
(Q)
(R)
(S)
Re-assemble：
To re-assemble your power chair, you can repeat disassembly directions in reverse.
