User's ManualHS-2850
On/Off
Button
Horn
Joystick
Speed Control Button
Self Diagnostic
Warning Lights &
Battery Gauge
Rear Bag
Armrest width
Adjustment
Thumbscrews
Armrest height Adjustment Thumbscrews
Rear Reflectors
Figure 1 - HS-2850 Power Chair Front View
Figure 2 - HS-2850 Joystick
Figure 3 - HS-2850 Power Chair Rear View
IDENTIFICATION OF PARTS
5
Before attempting to drive this power chair on your own, it is important that you familiarize
yourself with the controls and how they operate.
19" Mid-Back Seat
w/ Adj. Headrest & Seat Belt
Width & Height
Adjustable Armrests
Extended Footplate
with 3-Angle Adjustment
10"
Drive Wheels
