FOOTPLATE：
•Footplate
The footplate can be adjusted according to your specific needs. It can be width &
adjusted vertically or horizontally. To adjust footplate, loosen screw and arrange height
to desired position, then, tightened screw to secure plate in place. (D & E)
Figure 7
Figure 7
POWER BASE：
•Free-Wheeling Lever
When lever is in N (Neutral) position, power chair can be moved manually.
When lever is in D (Drive) position, power chair can be driven. Normal position is D.
Figure 8
Figure 8
(D)
(E)
