Instruction BookletHS-925
11
•When the scooter is in operation, the battery level will only decrease.
Battery Gauge :
Low Battery warning :
•Warning Condition : The low battery warning will be activated once the battery level is
less 25% of max capacity.
•Warning Sound : Be- Be-Be
•Recharge the scooter immediately when the battery level drops to 20% as the remaining
power can only keep scooter going for buffering 3km or less.
•The charging status will be displayed on full LCD screen
with cycling flash of battery level while charging.
(The scooter can not be operated while it is in charging.)
•As long as the charger connected to scooter charging
socket, the LCD panel will display “ in charging” indicator.
Please always refer to the indicators on battery charger for more accurate charging
status.
•After 10 seconds without pressing any button, LCD back light will be automatically off.
Press any button to turn on the back light.
Battery Charging Status Indication :
•If it is in low speed mode, LCD display will be [ L ]. LED indicator will be Orange light on.
•If it is in high speed mode, LCD display will be [ H ].
H / L Switch :
•Speed display range : 0.5~30.0
•Unit display : "km/h", speed will be indicated in km per hour.
Speed :
•ODO display range : 0~99999.9 km
•The odometer will be reset automatically to zero after the total distance reaching
99999.9km.
ODO meter :
•Display range : Centigrade -20~50°C or Fahrenheit -4~122°F (+- 2° difference)
Temperature :
Figure 10
Figure 11
Figure 9
Status Display
Capacity
(%)
>80 <80 <55 <35 <20
Do not set the speed at maximum when operating the scooter. Adjust the speed
at maximum when inclining a slope, and adjust to minimum speed when declining.
