Instruction BookletHS-925
13
•Release throttle, scooter will stop automatically but still slide for a short distance.
•If necessary, please use handbrake to stop scooter. (Figure 16)
Brake :
•Pull up the tiller adjustment latch to adjust for 3 different angles and release to lock at
a desired comfortable position. (Figure 17)
Tiller Angle Adjustment :
•Angle : Adjust the attached screw height to control
armrest’s angle. Pull the armrest up when getting
on or off the scooter. (Figure 18)
Armrest angle Adjustment :
Figure 16
Figure 17
Figure 15
AB
C
•Do not pull both right and left throttle at the
same time; you might not able to control the
scooter.
•Check surroundings before reversing to prevent any
danger.
•Do not adjust the tiller angle when driving.
•Please seat steady on the scooter. Do not stand on
the pedal during driving.
Figure 18
•Set at a comfortable position by lifting lever upwards to adjust the seat. (Figure 19)
Scooter Seat Fore-aft Adjustment (Optional, see section 9) :
•Set at a comfortable position by lifting lever upwards to adjust the seat. (Figure 20)
Rear Box as Seat Back Adjustment (Optional, see section 9) :
•Pull the swivel knob to rotate seat left and right. (Figure 21)
Scooter Seat Swivel Adjustment (Optional, see section 9) :
