Service Manual

S762A

1. SCOPE

This specification defines the design and performance requirements for the 17” SXGA TFT

LCD display monitor “S762A “.

The features of “S762A” is listed in the following table :

Feature Description

1 Universal input AC/DC power supply inside the monitor

2 Analog RGB interface (VGA ) 30~80KHz, 59~75Hz, 135MHz

3 17” SXGA 1280*1024, TFT LCD panel

Function keys * 5 : Power On/Off, ESC,△ (up), ▽ (down),

(enter)

Direct Acess function keys : △ for

contrast function, ▽ for brightness function .

ESC for audio mute function.(S761A/S762A/S760A only)

6 Green/Amber LED indicator for power on/power saving

7 Plug & play support with DDC2B protocol installed.

8 Power saving mode compliant with Energy Star

9 OSD (on screen display) MENU operation

9.1 Brightness adjustment

9.2 Contrast adjustment

9.3 Auto tune function (VGA)

9.4 Color selection

9.5 Image adjustment

9.6 Language selection

9.7 OSD position adjustment

9.8 Reset function

9.9 1W * 2 Audio function inside the monitor (S762A/S761A /S760A Only)

9.10 Volume adjust by OSD (S762A/S761A/S760A Only)
