Service Manual
S762A
6
Pin 1 Red
Pin 2 Green
Pin 3 Blue
Pin 4 No Connection
Pin 5 Ground
Pin 6 R Return
Pin 7 G Return
Pin 8 B Return
Pin 9 DDC +5V
Pin 10 Ground
Pin 11 Ground
Pin 12 SDA
Pin 13 H. Sync
Pin 14 V. Sync
Pin 15 SCL
2.3 Audio Input (S760A/S761A/S762A only)
2.3.1 Audio Input Signal Right &Left channels.
Input level: 1Vrms(typ), 2Vrms(max)
Input Impedance: 15Kohm
2.3.2 Audio Input Connection a. Detachable stereo phone head in two ends signal cable.
b. A female stereo phone jack base.
3. ELECTRICAL CHARACTERISTICS
3.1 LCD Panel
3.1.1. Type 17” diagonal, SXGA resolution, color TFT-LCD
3.1.2. Pixel structure R/G/B sub-pixels in vertical stripes
1280 x 1024 array matrix
a-Si TFT active matrix
3.1.3. Gray scale 16 million colors.
3.1.4. Surface treatment
3H hard coating, anti-static, anti-glare
3.1.5. Backlight
Integral CCFL, type to support field replacement.
Life time 30000 hours @ 25C, 50% of initial value.
3.1.6 Pixel Faults
Model
Project
Pixel Faults type
S762A/S761A/S760A/S762/S761/S760
LBL17S24HA01/LBL17B24HA01/LBL17W24HA01
LBL17S24HA/LBL17B24HA/LBL17W24HA
Type
Bright Pixels (Note 1)
≦ 5
Type
Dark Pixels (Note 2)
≦ 5
Type
Fault Pixels / Sub-Pixels(Note 3)
≦ 3
Type Cluster of type1 or type 2
f(
)
≦ 2
Type
Cluster of type3 faults (Note4)
≦ 3
Type
Total Pixel Faults
≦ 8
Note 1 : Bright pixels in full black pattern.
Note 2 : Dark pixels in full white pattern
Note 3 : fault Pixel / Sub-Pixel : The pixel or sub-pixel is abnormal but not bright/dark pixel.
Note 4 : Fault Cluster : Two or more Pixels/Sub-pixels with faults within 5 * 5 block of pixels.
